BISON

BISON

The King of Parks.

Engine

Engine

CAT C9.3B
CAT C9.3B
Power

Power

422 hp ECE @ 1,800 rpm
310 kW @ 1.800 rpm
Torque

Torque

1,399 ft-lb @ 1,400 rpm
1.897 Nm @ 1.400 rpm

Your Benefits

More Visitors to Your Parks

More Visitors to Your Parks

Park and funline builders rely on the Bison X to prepare perfect features in the tightest spots. The better the ride, the happier the customers.

Save Time and Money

Save Time and Money

Due to the combination of power and efficiency coupled with digital technologies that let the operator know the depth of snow, both time and money are saved.

Build parks faster

Build parks faster

The agility of the Bison together with the largest range of park building features we offer, enable you to build parks faster.

Configuration

Bison X has the most features for park and funline building that we offer. The X has twice the range of motion on the X Blade, extended tiller movement up to the vertical position, inclinometers for both vehicle and blade, and, unique to the Bison, a sideways-sliding swivel seat. Additionally, a distance measurement tool, LED lights, rearview camera, and a premium sound system, help X operators prepare and maintain park features more easily and with greater efficiency.

Extreme slopes are no problem for Prinoth’s Automatic Winch, which is reliable in all conditions and throughout varied terrain. This allows the operator to focus more on the blade and tiller helping to ensure a perfect finish. The winch pivot is located at the center of the groomer, ensuring neutral handling regardless of the pulling direction. The winch can be operated in three modes (Auto/Eco/Manual) with a maximum pulling force of up to 4.5t / 5 tn. Operators can prioritize pulling force or working speed. Due to the large radius of the drum and pulleys, less strain is put on the cable, increasing lifespan. Additionally, for ease of use, the included Roll-Out System enables the operator to easily pull out the winch cable.

The Bison can be an excellent addition to any Nordic Center, especially one with wider trails. For perfect classic tracks, attach a Power tiller and Nordic Liner, which guarantees cross country ski trails that meet Olympic standards. Two or four track setting plates and the track tillers can be used independently. They adjust position and surface pressure depending on the requirements and condition of the trail. The Skating finisher has a smaller profile than an alpine tiller, which produces a finer, narrower corduroy finish – ideal for a smooth skating glide.

King of Parks.

King of Parks.

The Bison not only has the power to climb the steepest slopes and the torque to push snow in all conditions but also boasts an amazingly comfortable cab. Plus, it's the most efficient groomer in its class.

Features

Custom Interface
The customizable Prinoth Control Unit is convenient and practical. Each operator can tailor the user interface with their preferred shortcuts and vehicle settings. This means that each time they take the sticks, their relevant settings are saved with the RFID key – making the start-up process faster.

Single Touch
The 12” tilting touchscreen makes everything easy to see at night or during the day. The rearview camera display can be changed to large or small on the screen. And most important, vital details about the machine such as quick access pages, engine, tiller and winch are always visible.

Prinoth Control Unit

Precise Control
An ergonomic joystick hand rest allows for hours of smooth, comfortable operation. The improved “joystick-in-joystick” design provides precise control and allows for simultaneous blade movement, making it easier for operators to push large piles of snow and cut razor sharp edges.

Straightforward Service
The latest generation of the proven CAN-bus-controlled system, optimizes the movements of the attachments and reduces the number of tubes. This results in customizable blade movements and easier maintenance and service on the machine.

Joystick-in-Joystick

Modern, Stylish, Quiet
It’s all about the operator. The larger cabin, generous footwell with heating system, integrated sunroof and ergonomic design (including the tailored Recaro seats) create a comfortable home base for producing the perfect finish. Choose fully automated air conditioning for complete temperature control no matter what’s happening outside.

Cabin Comfort

Standard Center Seat
The standard center seat allows operators to see better whether free grooming or park building.

Unique Sliding Seat Technology
Choose the optional sideways-sliding swivel seat to move between center and left positions. The seat moves up for 500 mm which, coupled with the 15 degree turning radius, provides the operator with the best all-around view – a real advantage when building parks and pipes.

Seating Options

Ideal Power Performance
The Caterpillar C9.3B engine offers unrivaled performance. The straight-six engine produces max torque at the optimum engine speed of 1,400 rpm; meaning you have ideal power performance within the recommended running range.

Impressively Low Emissions
This machine meets the world’s highest emission standards—Euromot Stage V. In addition to diesel, it can also run on HVO, GTL or BTL without any modifications needed to the engine. This means ski resorts can stick with standard diesel or explore alternative fuels to help minimize CO2 yet further.

An exhaust treatment system with SCR catalytic converter, oxidation catalyst and diesel particulate filter reduces emissions to a minimum. These upgrades make the Bison the cleanest snow groomer in its class.

Power and Sustainability

The low center of gravity guarantees stability going uphill and downhill. A turning radius of zero (around its own axis) improves the agility, and the standard center seat position provides the operator with the best possible view.

Full Balance

Technical data

Download (PDF)
  • Engine

    CAT C9.3B
    CAT C9.3B
  • Power

    422 hp ECE @ 1,800 rpm
    310 kW @ 1.800 rpm
  • Torque

    1,399 ft-lb @ 1,400 rpm
    1.897 Nm @ 1.400 rpm
  • Cylinder and Displacement

    Straight-6, 9.3 L
    Straight-6, 9.3 L
  • Emission standard

    Straight-6, 9.3 L Euromot Stage V / Tier 4 final
    Straight-6, 9.3 L Euromot Stage V / Tier 4 final
  • Track working width

    13'10" / 14'
    4.210 / 4.260 mm
  • Vehicle length (without blade/tiller)

    15'2"
    4.630 mm
  • Total length with attachments (POSIFLEX Tiller)

    29'5"
    8.960 mm
  • Total length with attachments (Power Tiller)

    29'2"
    8.880 mm
  • Total height with tracks (without winch)

    9'11"
    3.030 mm
  • Blade width with side wings open (Master)

    19'3"
    5.360 mm
  • Blade width with side wings closed (Master)

    14'9"
    4.485 mm
  • Blade width with side wings open (X)

    18'10"
    5.751 mm
  • Blade width with side wings open and shaping kit mounted (X)

    19'1''
    5.818 mm
  • Blade width with side wings closed (X)

    15'2"
    4.627 mm
  • Tiller with side wings raised (POSIFLEX)

    17'7"
    5.365 mm
  • Tiller with side wings lowered (POSIFLEX)

    19'10"
    6.045 mm
  • Tiller with side wings raised (POWER)

    17'9"
    5.400 mm
  • Tiller with side wings lowered (POWER)

    20'4"
    6.200 mm
  • Tank capacity

    84.5 gal* / 70 gal (* with additional fuel tank)
    320 L* / 265 L (* with additional fuel tank)
  • Fuel Types

    Diesel, HVO, GTL and BTL (According to the norms ASTM D975, EN590, EN15940)
    Diesel, HVO, GTL and BTL (According to the norms ASTM D975, EN590, EN15940)
  • AdBlue®/DEF capacity

    8 gal
    30 L
  • Weight with tracks, blade, tiller

    from 21,411 lbs
    from 9.712 kg
  • Winch weight (850 m cable)

    from 4,621 lbs
    from 2.096 kg
  • Winch pulling force

    5 tn
    44.1 kN / 4.5 t

Attachments

Attachments
Power Tiller

Power Tiller

The Power Tiller produces deep, fine-grained grooves which means sensational slope quality that lasts.

Closed Steel Tracks

Closed Steel Tracks

These tracks are ready to work on the toughest conditions. With their heavy duty durability, they perform on surfaces that vary from snow to rocky ground.

Gamskette (Aluminum) Tracks

Gamskette (Aluminum) Tracks

With their excellent climbing abilities and maneuverability, these long-lasting tracks are made for all types of vehicles. They feature overlapping locks.

Open Steel Tracks

Open Steel Tracks

The open-profile is idea for fresh and powder snow, and can be used on roads or fields. The overlapping lock simplifies handling and makes them easy to service.

Automatic Winch

Automatic Winch

The winch has a pulling force 4.5t/5TN and can be operated in 3 modes: Auto/Eco/Manual. The pivot is located in the center, ensuring neutral handling.

Nordic Liner Basic

Nordic Liner Basic

2 or 4 track setting plates which set long-lasting tracks that meet the highest Olympic standards. Track pans and track tillers can be used independently.

Master Blade

Master Blade

This best-in-class blade can push enormous amounts of snow while producing precise slope edges, allowing for fewer passes.

Leitwolf & Bison Transport Cabin

Leitwolf & Bison Transport Cabin

The multipurpose Transport Cabin for Leitwolf & Bison was developed for two main purposes - transporting people and carrying materials.

X Blade

X Blade

The X Blade is designed to save time when building parks and funlines. It can also be used for easy tool transportation.
